Motor: 1/3
h.p., grease packed ball bearing, air-cooled, 110/60/1 (50Hz
available) Controls:
The following controls
are standard on all Spar Mixers: separate start and emergency stop
buttons so operators can shut down the mixer immediately in an
emergency situation, and thermal overload protection Cord and Plug: 6 ft. flexible three wire
cord and ground prong. Transmission:
Heat-treated,
hardened alloy, precision milled gears operate with planetary
action. Gears are packed in a long-lasting, high pressure grease.
Planetary gears are driven by direct linkage to the motor drive
shaft. This design yields high-torque mixing power. Speeds:
(Agitator rpm), (Hub
rpm’s)
1. Low Speed 106, 59
2. Intermediate Speed 196, 110
3. High Speed 358, 201 Bowls and Agitators: Standard equipment
includes a 10Qt. high quality stainless steel bowl, dough hook, flat
beater, and whip. A sturdy hand lever on the body column raises and
lowers the bowl as well as locking in place at the top and bottom
positions. Attachments:
Standard is the No. 12
hub for powering a standard size vegetable slicer/cheese shredder
and a standard size meat mincer/grinder. Finish: Top (transmission cover):
metallic bronze epoxy enamel
Bottom: metallic gray epoxy enamel Shipping Information:
N.W. 176lbs
(70kgs)
G.W. 220lbs
(90kgs)
Carton Size: Depth 24in.(60cm) Width 23in.(58cm) Height
37.8in.(96cm)
Cartons are affixed to an undersized skid (pallet), the weight and dimensions
of this skid are not included above and may vary from shipment to
shipment.
