Click here
to compare the SP-25 specs to other mixers.
Motor:
3/4 h.p. (.5kW), grease packed ball bearing, air-cooled, 120/60/1
(50Hz available) Controls:
Spar Mixer controls are front-mounted to give easy access
in cramped kitchen environments. The following controls are
standard on all Spar Mixers: separate start and emergency
stop buttons so operators can shut down the mixer immediately
in an emergency situation, a 15-minute timer which shuts off
the machine after set time has elapsed, and thermal overload
protection Cord and Plug: 6 ft. flexible three
wire cord and ground prong. Transmission:
Heat-treated, hardened alloy, precision milled gears operate
with planetary action. Gears are packed in a long-lasting,
high pressure grease. Planetary gears are driven by an oversized
cog-wheel, which is in turn driven by a cogged belt powered
by the motor drive shaft. Cogged belt is a long-lasting, rugged
fiber/rubber composite. This unique design yields high-torque
mixing power while avoiding the high cost encountered repairing
direct-drive transmission components. Speeds:
(Agitator rpm)
1. Low Speed 102
2. Intermediate Speed 183
3. High Speed 352 Bowls and Agitators:
Standard equipment includes a 24.3Qt. (23L) high quality stainless
steel bowl, dough hook, flat beater, and whip. A sturdy hand
lever on the body column raises and lowers the bowl as well
as locking in place at the top and bottom positions. Attachments: Standard is the No.
12 hub for powering a standard size vegetable slicer/cheese
shredder and a standard size meat mincer/grinder. Finish:
Top (transmission cover): metallic bronze epoxy enamel
Bottom: metallic gray epoxy enamel Shipping Information:
N.W. 264lbs
(120kgs)
G.W. 308lbs
(140kgs)
Carton Size: Depth 24in.(61cm) Width 26.4in.(58cm) Height
40.2in.(102cm)
Cartons are affixed to an undersized skid (pallet), the weight
and dimensions of this skid are not included above and may
vary from shipment to shipment.
