Motor:
3 h.p. (1.5kW), grease packed ball bearing, air-cooled,
208/60/1, 208/60/3, 220/60/1, 240/60/3 (50Hz available)
Controls:
Spar Mixer controls are front-mounted to give easy access in cramped
kitchen environments. The following controls are standard on all
Spar Mixers: separate start and emergency stop buttons so operators
can shut down the mixer immediately in an emergency situation, a
15-minute timer which shuts off the machine after set time has
elapsed, and thermal overload protection
Cord and Plug:
Both single phase and three phase are hard wired
Transmission:
Heat-treated, hardened alloy, precision milled gears operate
with planetary action. Gears are packed in a long-lasting, high
pressure grease. Planetary gears are driven by an oversized
cog-wheel, which is in turn driven by a cogged belt powered by the
motor drive shaft. Cogged belt is a long-lasting, rugged fiber/rubber
composite. This unique design yields high-torque mixing power while
avoiding the high cost encountered repairing direct-drive
transmission components.
Speeds:
(Agitator rpm), (Slicer/Grinder rpm)
1. Low Speed 99, 60
2. Intermediate Speed 176, 108
3. High Speed 320, 197
Bowls and Agitators:
Standard equipment includes a 54.3Qt. (60L) high quality stainless
steel bowl, dough hook, flat beater, and whip. A sturdy hand lever
on the body column raises and lowers the bowl as well as locking in
place at the top and bottom positions.
Attachments: Standard is the No. 12 hub
for powering a standard size vegetable slicer/cheese shredder and a
standard size meat mincer/grinder.
Finish:
Top (transmission cover): metallic bronze epoxy enamel
Bottom: metallic gray epoxy enamel
Shipping Information:
N.W. 572lbs
(260kgs)
G.W. 660lbs
(300kgs)
Carton Size: Depth 35in.(88cm) Width 30in.(75cm) Height 59in.(149cm)
Cartons are affixed to an undersized skid (pallet), the weight and dimensions
of this skid are not included above and may vary from shipment to
shipment.
